YBM Series 12kV Compact Outdoor Prefabricated Substation

Overview

The YBM Series prefabricated substation is a compact outdoor power distribution solution designed for medium voltage electrical systems. It integrates the transformer, medium voltage switchgear and low voltage distribution equipment into one compact unit, helping reduce installation space and simplify on-site construction.

The compact substation is suitable for industrial plants, commercial buildings, infrastructure projects, solar power systems and other medium voltage distribution applications. The internal configuration can be customized according to the required voltage level, transformer capacity, protection requirements and low voltage distribution system.

Key Features

• Compact integrated structure — the prefabricated substation adopts an integrated structure that combines the major electrical equipment within a compact enclosure.
• Reduced installation footprint — the compact design reduces the installation footprint compared with a conventional substation arrangement.
• Convenient transport and installation — the integrated structure makes transportation and installation more convenient.
• Transformer integration — the transformer, medium voltage switchgear and low voltage distribution equipment are integrated into one unit.
• Customizable internal configuration — the arrangement can be customized for the required voltage level, transformer capacity, protection requirements and low voltage distribution system.
• Outdoor construction — designed as an outdoor solution for medium voltage distribution applications.

Technical Specifications

Applications

• Industrial plants.
• Commercial buildings.
• Infrastructure projects.
• Solar power systems.
• Other medium voltage distribution applications.

Installation Conditions

• The substation is designed for outdoor installation — confirm the site arrangement and cable entry provisions.
• The compact integrated structure reduces the installation footprint and makes transport and installation more convenient; confirm the transport route and lifting arrangements.
• The internal configuration can be customized to the required voltage level, transformer capacity, protection requirements and low voltage distribution system.
• Confirm the protection requirements of the medium voltage and low voltage sections before installation.

How to Select

• The voltage level of the medium voltage distribution system.
• The transformer capacity required.
• The transformer type appropriate to the application.
• The medium voltage switchgear and protection requirements.
• The low voltage distribution system configuration.
• The cable entry arrangement.
• The installation environment and enclosure requirements.
