Overview

When space is tight but reliability cannot be compromised, the SRM6-12 delivers. This 12kV switchgear platform packs switching, protection, and fault interruption into a single compact enclosure.

Choose from load break switch, fuse-switch, or vacuum breaker configurations to match your network needs. The rugged housing stands up to moisture, dust, and temperature extremes, making it suitable for underground vaults, substations, and industrial sites. The platform is fully type-tested to IEC 62271-200 and GB3906 standards.

Key Features

• Flexible configuration options — one platform supports three variants — load break switch for line switching, fuse-switch combination for transformer protection, or vacuum circuit breaker for fault interruption. Select the right fit without redesigning your network.
• Built for harsh environments — the rugged enclosure withstands high humidity, heavy dust, and extreme temperature swings, and can be installed in underground vaults, coastal areas, or industrial zones without added protection.
• Space-saving compact design — a small footprint fits easily into confined spaces like modular substations, prefabricated switchrooms, and urban cable pits, with no costly civil works required.
• Low lifecycle costs — no routine maintenance is needed over its entire service life, significantly reducing operational expenses.
• Proven across diverse applications — extensively deployed in urban grids, commercial complexes, manufacturing plants, and renewable energy sites.
• Globally certified quality — fully type-tested to IEC 62271-200 and GB3906 standards, meeting international and Chinese grid requirements.

Technical Specifications

Applications

• Urban power distribution — deployed in underground ring networks, compact substations, and cable distribution rooms across cities, handling high-density loads with reliable switching and protection.
• Commercial and residential complexes — installed in basements or dedicated utility rooms of shopping malls, high-rise buildings, and residential communities, where the compact size fits limited building service areas.
• Industrial and mining facilities — operates reliably in manufacturing plants, refineries, and mining sites where dust, moisture, and temperature variations are common.
• Renewable energy projects — integrates into solar farms and wind power plants for collector line protection and grid interconnection, adapting to remote outdoor sites.
• Indoor and sheltered outdoor locations — designed for installation in substations, switchrooms, cable vaults, and similar protected environments.

Installation Conditions

• Temperature range — the unit operates reliably across ambient temperatures from -25°C to +55°C, performing consistently in both cold climates and high-heat industrial settings.
• Humidity and dust resistance — it withstands high humidity and dusty environments without performance loss, with no additional filtration or climate control systems typically required.
• Network topology compatibility — it works with both ring and radial distribution networks, and existing system configurations generally need no major modifications for integration.
• Compact space adaptability — the small footprint allows placement in confined areas such as underground pits, modular substations, and prefabricated switchgear rooms, with no special foundation or structural reinforcement needed.
• The unit is intended for indoor or sheltered outdoor locations and is not designed for direct outdoor exposure without additional shelter.

How to Select

• Which variant suits the circuit — load break switch for line switching, fuse-switch combination for transformer protection, or vacuum circuit breaker for fault interruption.
• The rated current and breaking duty required by the network.
• Whether the network topology is ring or radial.
• The ambient temperature range and humidity or dust conditions at the site.
• The available space and whether a confined installation such as an underground pit or prefabricated switchroom is involved.
• Whether additional shelter is required for a sheltered outdoor location.
