Overview
The S13 Series Oil Immersed Distribution Transformer is designed for reliable medium voltage power distribution in industrial, commercial and infrastructure applications. It uses insulating oil for both electrical insulation and heat dissipation, which keeps the windings cool under continuous load.
The transformer steps medium voltage electricity down to the low voltage required by factories, commercial buildings, infrastructure facilities and other electrical loads. Rated capacity, primary and secondary voltage, vector group, impedance and installation environment are all selected to suit the individual distribution project rather than fixed at a single rating.
The S13 can also be supplied as part of a prefabricated substation together with medium voltage switchgear and low voltage distribution equipment, allowing the whole distribution point to be assembled and tested as a coordinated unit.
Key Features
- Oil immersed construction — insulating oil provides both dielectric strength and heat transfer, which suits outdoor distribution duty and continuous loading.
- Efficient magnetic core — a laminated core reduces no-load loss, which is the part of the loss that applies continuously while the transformer is energised.
- Reliable winding structure — the winding arrangement is designed to withstand the mechanical forces produced by short-circuit currents.
- Oil cooling system — heat generated by the windings and core is transferred to the oil and dissipated through the tank and radiators.
- Flexible capacity range — multiple capacity options are available so the rating can match the connected load instead of being over- or under-sized.
- Flexible voltage configuration — primary and secondary voltage combinations are selected for the project.
- Outdoor installation — the oil immersed tank construction is suited to outdoor mounting.
- Easy integration — can be combined with MV switchgear and LV distribution equipment in a prefabricated substation.
Technical Specifications
| Model | S13 |
|---|---|
| Type | Oil immersed distribution transformer |
| Rated voltage class | 10 kV |
| Rated capacity | Multiple options, selected to project load |
| Primary voltage | Configured to project requirements |
| Secondary voltage | Configured to project requirements |
| Vector group | Configured to project requirements |
| Impedance (%Z) | Configured to project requirements |
| Cooling type | Oil immersed (oil cooling) |
| Installation | Outdoor |
| Frequency | 50 Hz |
Applications
- Industrial plants and factory distribution systems
- Commercial buildings and facilities
- Infrastructure and utility distribution projects
- Distribution points built as prefabricated substations
- Urban and rural power distribution networks
How to Select
- Capacity (kVA) required by the connected load
- Primary voltage
- Secondary voltage
- Vector group
- Impedance (%Z)
- Cooling type
- Installation environment
- Frequency
FAQ
What is the S13 transformer used for?
The S13 Series Oil Immersed Distribution Transformer is used to step medium voltage electricity down to the low voltage required by factories, commercial buildings, infrastructure facilities and other electrical loads.
What does "oil immersed" mean?
The core and windings are immersed in insulating oil inside the tank. The oil provides both electrical insulation and heat dissipation, transferring heat from the windings to the tank and radiators.
What capacities are available?
The S13 series is offered in multiple capacity options. The rating is selected to match the connected load of the project, so the correct capacity should be confirmed from the load calculation before ordering.
Can the voltage ratio be customised?
Yes. Primary voltage, secondary voltage, vector group and impedance are all configured to the requirements of the individual distribution project.
Can the S13 be installed outdoors?
Yes. The oil immersed tank construction is suited to outdoor installation.
Can the S13 be combined with other equipment?
Yes. The transformer can be supplied as part of a prefabricated substation together with medium voltage switchgear and low voltage distribution equipment.
